SC APC Fiber Optic Patch Cord 3.0mm PVC/Yellow SM Fiber Optic Jumper Cable

SC APC Fiber Optic Patch Cord 3.0mm PVC/Yellow SM Fiber Optic Jumper Cable

Large Image :  SC APC Fiber Optic Patch Cord 3.0mm PVC/Yellow SM Fiber Optic Jumper Cable

Product Details:

Place of Origin: Shenzhen , China
Certification: CE,RoHS,FCC,CPR,ISO9001

Payment & Shipping Terms:

Minimum Order Quantity: 100pcs
Price:
Packaging Details: PE bag
Delivery Time: 3-15 days
Payment Terms: L/C,T/T,Western Union payments for offline orders.
Supply Ability: 1 million connector / month
Contact Now
Detailed Product Description
Detailed Product Description
Fiber Type: G652D,G657A1 Cable Jacket: PVC,LSZH,PE
Cable Coloe: Yellow Certification: ISO9001:2008
High Light: fiber patch cord, sc fiber patch cord





Features

  • In line with Telcordia GR-326-CORE standard
  • Low insertion loss,high return loss,high reliability
  • Good repeatability,interchangeability
  • Any diameter of fiber can be chose ,0.9mm,2mm,3mm ,
  • 10G fiber,Low Smoke and Zero Halogen can be chose.



Application

  • Fiber optic communcation system;
  • Fiber optic data transmission;
  • LAN , CATV ;
  • Fiber optic testing system.

Specification:



Item Unit SC
SM MM
PC UPC APC PC
Insertion loss(typical) dB ≤0.3 ≤0.2 ≤0.3 ≤0.2
Return loss dB ≥45 ≥50 ≥60 ≥30
Operating wavelength nm 1310,1510
Exchangeability dB ≤0.2
Vibration dB ≤0.2
Operating temperature ℃ -40～75
Storage temperature ℃ -45～85
Cable diameter mm φ3.0 ,φ2.0 ,φ0.9




Ordering Information

  • For Example: FC/PC-FC/PC-SM-SX-φ3.0-3M
  • Connector Type:FC,SC,LC,ST,MPO,MTRJ,MU,E2000,D4,DIN,SMA
  • Ferrule End-face:PC,UPC,APC
  • Core Type: Single-mode(SM:9/125μm), Multimode(MM:50/125μm or 62.5/125μm)
  • Product Structure:“DX”means Duplex,“SX”means Simplex
  • Fiber Diameter: φ3.0mm,φ2.0mm,φ0.9mm
  • Cable Length:1,2,3meter or customized.
  • Cable Type:PVC,LSZH,OM3,OFNP














Tag:sc fiber patch cord,fiber patch cord,st patch cord
