Screw-thread coupling mechanism single or duplex mode available DIN Fiber Optic Patch Cord

Detailed Product Description

Product Name:	Fiber Optic Patch Cord	Ferrule End-face:	PC, UPC, APC
Core:	Simplex, Duplex	Cable Diameter:	Ф3.0mm, Ф2.0mm, Ф0.9mm
Cable Length:	1, 2, 3 Meter Or Customized	Cable Type:	PVC, LSZH, OM3, OFNR, OFNP
High Light:	sc fiber patch cord, st patch cord



Screw-thread coupling mechanism single or duplex mode available DIN Fiber Optic Patch Cord
DIN Fiber Optic Patch Cord

DIN fiber optic patch cord is a fiber optic cable used to attach one device to another  for signal routing.



Features & Availabilities
Screw-thread coupling mechanism
Singlemode and multimode available
PC and APC polishing available
Interferential parameters available
Hybrid patch-cords are available upon request
Pigtail available



Application:

1.FTTH , CATV, LAN, MAN, WAN, Test &Measuremen2.Video transmission , Data transmission3.Active Device Termination4.Premise Installations5.Telecommunication and Data processing Networks6.Industrial, medical & military7.Systems Integration for Long Haul, Metro and Access Network


Specifications

Insertion loss	Singlemode	PC≤0.3dB	UPC≤0.2dB	APC ≤0.3dB
	Multimode	PC≤0.3dB	UPC≤0.3dB	APC ≤0.3dB
Return loss	Singlemode	PC≥50dB	UPC≥50dB	APC ≥60dB
	Multimode	PC≥50dB	UPC≥50dB	APC ≥50dB
Reparability	≤0.1dB
Changeability	≤0.2dB
Working temperature	-40 to +80°C
Durability	1000 times
Sustain tension	≥100N
Fiber	9/125um , 50/125um,  62.5/125um,  OM3
Diameter	0.9mm, 1.8mm, 2.0mm 3.0mm,  etc.
Cable material	PVC,  LSZH, Plenum
Cores	Simplex,  duplex,  4cores,  6cores,  8cores, 12cores,  etc.


Ordering Information:
DIN/PC-DIN/PC-SM-SX-3.0-2M
①    ②   ①   ②  ③  ④   ⑤   ⑥
①Connector type: FC, SC, LC, ST, MTRJ, MU, E2000, MPO, DIN, D4, SMA
②Ferrule End-face: PC, UPC, APC
③Core Type: Single-mode (SM: 9/125um), Multimode (MM: 50/125um or 62.5/125um)
④Cable Quantity: “DX” means Duplex / “SX” means Simplex
⑤Cable Diameter: Ф3.0mm, Ф2.0mm, Ф0.9mm
⑥Cable Length: 1, 2, 3 meter or customized
⑦Cable type: PVC, LSZH, OM3, OFNR, OFNP, Plenum
